MVL-AF4028M-M42
mvl-af4028m-m42
Lens
The Hikrobot MVL-AF4028M-M42 is an FA / machine-vision lens with 40 mm focal length, M42 × P1.
Image circle Φ37 mm. Aperture F2.8 to F22. Optical distortion 0.62%. Iris: Manual. Focus: Manual. Filter thread M37 × 0.75.
Mid-range focal length: size FOV and WD against sensor format and required pixels-on-feature. Mount M42 × P1 for larger formats or line-scan; account for flange distance and any adapter in the optical path.
Select variant
SKU: mvl-af4028m-m42
Specifications
| Certification | RoHS 2.0 |
|---|---|
| Dimension | Φ47.6 mm × 62.7 mm (Φ1.9" × 2.5") |
| F-number | F2.8 to F22 |
| Filter thread | M37 × 0.75 |
| Flange back length | 12 mm |
| Focal length | 40 mm |
| Focus control | Manual |
| Image size | Φ37 mm |
| Iris control | Manual |
| Magnification range | 0.22 x to 0.04 x |
| Mount | M42 × P1 |
| Optical distortion | 0.62% |
| Temperature | –10 °C to 50 °C (14 °F to 122 °F) |
| Weight | 171 g (0.4 Ib.) |
| Working distance range | 200 mm to 1051 mm |
