MV-GT1002
mv-gt1002
Vision Components
MV-GT1002 is a vision-system component for connecting, powering or interfacing industrial cameras. Use it only with the stated connector, interface and bandwidth or electrical rating. Check cable length, connector orientation and compatibility with the camera and host system.
Select variant
SKU: mv-gt1002
Prijs op aanvraag
Specifications
| Camera connection speed | 10 Gbps |
|---|---|
| Camera quantity supported | 2 at most |
| Camera type supported | GigE industrial camera and 10 GigE industrial camera |
| Certification | CE, KC, RoHS |
| Client software | MVS |
| Connector | 9-pin header |
| Delivery bandwidth | 3900 MB/s (max. transmission bandwidth) 3350 MB/s (sustained transmission bandwidth) |
| Dimension | 181 mm × 126.3 mm × 21.4 mm (7.1" × 5.0" × 0.8") |
| Humidity | 10% RH to 95% RH (no condensation) |
| I/O Type | Configurable input/output × 8, compatible with single-ended/differential Line 0/1/4/5/6/7 supports 3.3 VDC to 12 VDC input, and 3.3 VDC output Line 2/3 supports 3.3 VDC to 24 VDC input and 3.3 VDC output |
| Indicator | 1 |
| Interconnect | PCI-E gen2 × 8 |
| Interface | RJ45 × 2 |
| On-board memory | 2 GB DDR3-RAM |
| Operating system | Windows 7/10/11, Ubuntu18.04 to 22.04 on Linux |
| Pixel format | Mono 8/10/10p/12/12p/16 Bayer 8/10/10p/12/12p YUV422Packed, YUV422_YUYV_Packed RGB 8, BGR 8 |
| Power consumption | Typ. 19.2 W |
| Standard | GigE Vision V2.0 |
| Stream | 2 |
| Stream indicator | 2 pairs |
| Temperature | Working temperature: 0 °C to 60 °C (32 °F to 140 °F) Storage temperature: –20 °C to 70 °C (–4 °F to 158 °F) |
