MV-ID2016M-06S-BBN
Fast Ethernet (100 Mbit/s) · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-BBN
mv-id2016m-06s-bbn
Smart Code Reader
The Hikrobot MV-ID2016M-06S-BBN (ID reader) is a fixed-mount smart code reader for 1D/2D codes and DPM in triggered or free-run station setups.
Imager 1408 × 1024. 60 fps. Mono Illumination 0 lux to 50000 lux.
Variants differ in focal length, lighting, and cover (including polarization): narrower FOV / longer focal length for fine modules at distance; wider FOV for larger labels closer in.
Beschikbare configuraties
- mv-id2016m-06s-bbn — Fast Ethernet (100 Mbit/s) · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-BBN
- mv-id2016m-06s-rbn — Fast Ethernet (100 Mbit/s) · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-RBN
- mv-id2016m-06s-wbn — Fast Ethernet (100 Mbit/s) · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-WBN
- mv-id2016m-06t-rbp — Fast Ethernet (100 Mbit/s) · M12-mount · 16 μs to 20000 μs · 06T-RBP
- mv-id2016m-10t-rbp — Fast Ethernet (100 Mbit/s) · M12-mount · 16 μs to 20000 μs · 10T-RBP
- mv-id2016m-16s-rbn — Fast Ethernet (100 Mbit/s) · M12-mount, adjusting focus manually supported · 16 μs to 1 sec · 16S-RBN
- mv-id2016m-16t-rbn — Fast Ethernet (100 Mbit/s) · M12-mount · 16 μs to 20000 μs · 16T-RBN
- mv-id2016m-25s-rbn — Fast Ethernet (100 Mbit/s) · M12-mount, adjusting focus manually supported · 16 μs to 1 sec · 25S-RBN
- mv-id2016m-06s-bbn-u — USB 3.0 · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-BBN-U
- mv-id2016m-06s-rbn-u — USB 3.0 · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-RBN-U
- mv-id2016m-06s-wbn-u — USB 3.0 · M10-mount, adjusting focus manually supported · 16 μs to 1 sec · 06S-WBN-U
Select variant
SKU: mv-id2016m-06s-bbn
Specifications
| Ambient illumination | 0 lux to 50000 lux |
|---|---|
| Certification | CE, RoHS, KC |
| Client software | IDMVS |
| Gain | 0 dB to 15 dB |
| Humidity | 20% RH to 95% RH (no condensation) |
| Ingress protection | IP65 |
| Max. frame rate | 60 fps |
| Mono/color | Mono |
| Data interface | Fast Ethernet (100 Mbit/s) |
| Exposure time | 16 μs to 1 sec |
| Lens mount | M10-mount, adjusting focus manually supported |
| Model | 06S-BBN |
| Pixel size | 3.45 μm × 3.45 μm |
| Resolution | 1408 × 1024 |
| Sensor size | 1/2.9" |
| Sensor type | CMOS, global shutter |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
