MV-IDH9000-13DP-04RP-L
Fast Ethernet (100 Mbit/s), RS-232, DC terminal · 650 nm laser (red light)
mv-idh9000-13dp-04rp-l
Handheld Code Reader
MV-IDH9000-13DP-04RP-L is een Sedeco handheld code reader op basis van de live catalogusgegevens: CMOS · 1280 × 1024 · Diffused reflection lighting (red LED), bi-directional lighting (red LED), direct lighting (white LED), polarized lighting (white LED) Smart scanning mode is set by default, and auto polling of lights is supported according to the code reading scene. · IP67 · IDMVS-software. Configureer de passende variant voor uw station; neem contact op met Sedeco voor selectieondersteuning.
Beschikbare configuraties
- mv-idh9000-13dp-04rp-l — Fast Ethernet (100 Mbit/s), RS-232, DC terminal · 650 nm laser (red light)
- mv-idh9000-13dp-04rp-u — USB 2.0, DC terminal · 650 nm laser (red light)
- mv-idh9000-13hhd-16rp-l — Fast Ethernet (100 Mbit/s), RS-232, DC terminal · 650 nm laser (red light) + LED (green light)
- mv-idh9000-13hhd-16rp-u — USB 2.0, DC terminal · 650 nm laser (red light) + LED (green light)
Select variant
SKU: mv-idh9000-13dp-04rp-l
Specifications
| Ambient illumination | 0 lux to 100000 lux |
|---|---|
| Certificering | CE, KC |
| Chemically resistant | ISO 16750 |
| Clientsoftware | IDMVS |
| Detection angle | Tilt angle ± 60°, skew angle ± 60°, rotation angle 360° |
| Afmetingen | 74 mm × 109.9 mm × 227.1 mm (2.9" × 4.3" × 8.9") |
| Display | 0.96" OLED display |
| Luchtvochtigheid | 5% RH to 95% RH (geen condensatie) |
| Beschermingsgraad | IP67 |
| Laser safety class | Laser 2 |
| Lichtbron | Diffused reflection lighting (red LED), bi-directional lighting (red LED), direct lighting (Witte LED), polarized lighting (Witte LED) Smart scanning mode is set by default, and auto polling of lights is supported according to the code reading scene. |
| Max. stroomverbruik | 5.5 W |
| Maximum power | 1 mW |
| Aiming system | 650 nm laser (red light) |
| Datainterface | Fast Ethernet (100 Mbit/s), RS-232, DC terminal |
| Prompt | LED indicator, buzzer, vibrator |
| Pulse width | 6.6 ms |
| Resolutie | 1280 × 1024 |
| Sensortype | CMOS |
| Static electricity resistant | ± 25 kV (air discharge), ± 10 kV (contact discharge or indirect discharge) |
| Symbol contrast | 20% |
| Symbologies | 1D codes: Code 39, Code 93, Code 128, CodaBar, EAN8, EAN13, ITF25, ITF14, UPCA, UPCE 2D codes: QR Code, Data Matrix, MicroQR, AZTEC Stacked barcode: PDF417 |
| Temperatuur | Werktemperatuur: –10 °C to 50 °C (14 °F to 122 °F) Opslagtemperatuur: –20 °C to 60 °C (–4 °F to 140 °F) |
| Wavelength | 650 nm |
