MV-DB500S-S
mv-db500s-s
3D Camera
De Hikrobot MV-DB500S-S is een 3D-camera voor diepte, hoogte en pose — taken waar een 2D-grijswaardebeeld onvoldoende geometrie levert (grijpen, volume, hoogtetoleranties).
Accuracy: X, Y: 2.6 mm@ 1 m; 5.5 mm@ 2 m. Measurement range: 1500 mm. Frame rate: 25 fps@ singulation mode. Data type: Original image (mono en color images), depth image, object posture information. Data interface: Gigabit Ethernet.
Select variant
SKU: mv-db500s-s
Specifications
| Certificering | KC |
|---|---|
| Clearance distance (CD) | 500 mm |
| Clientsoftware | robotic parcel-feeding system, HiViewer |
| Color image detection accuracy | X, Y: 2.6 mm@ 1 m; 5.5 mm@ 2 m |
| Datainterface | Gigabit Ethernet |
| Data type | Original image (mono and color images), depth image, object posture information |
| Depth image detection accuracy | X, Y: 5 mm@ 1 m; 10 mm@ 2 m Z: 5 mm@ 1 m; 10 mm@ 2 m |
| Digitale I/O | 12-pin M12 interface provides I/O, including opto-isolated input × 3 (Line 0/3/6), opto-isolated output �� 3 (Line 1/4/7) |
| Afmetingen | 200 mm × 47 mm × 100 mm (7.9" × 1.9" × 3.9") |
| Far field of view | 2500 mm × 1800 mm |
| Luchtvochtigheid | 20% RH to 85% RH, niet-condenserend |
| Beschermingsgraad | IP65 |
| Laser safety class | Class 1 |
| Measurement range (MR) | 1500 mm |
| Near field of view | 580 mm × 470 mm |
| Object detection range | 50 mm × 50 mm × 10 mm to 1000 mm × 1000 mm × 1000 mm |
| Besturingssysteem | 32/64-bit Windows 7/10 |
| Stroomverbruik | Avg. 5.5 W@ 24 VDC |
| Voeding | 12 VDC to 24 VDC |
| Scan frame rate | 25 fps@ singulation mode |
| Temperatuur | Werktemperatuur: 0 °C to 45 °C (32 °F to 113 °F) Opslagtemperatuur: –30 °C to 80 °C (–22 °F to 176 °F) |
| Gewicht | Circa 1 kg (2.2 lb.) |
